| TOP224YN COUNTRY OF ORIGIN | ||||||||||||||||||||||
| TOP224YN PARAMETRIC INFO |
||||||||||||||||||||||
| TOP224YN PACKAGE INFO |
||||||||||||||||||||||
| TOP224YN MANUFACTURING INFO |
||||||||||||||||||||||
| COUNTRY OF ORIGIN | ||||||||||||||||||||||
| Malaysia | ||||||||||||||||||||||
| Japan | ||||||||||||||||||||||
| China | ||||||||||||||||||||||
| Thailand | ||||||||||||||||||||||
| PARAMETRIC INFO |
||||||||||||||||||||||
|
| Supplier packaging | TO-220 |
| Basic package type | Through Hole |
| Number of pins | 3 |
| Pin shape | Through Hole |
| PCB | 3 |
| ears | ears |
| Pin spacing (mm) | 2.79(Max) |
| Package length (mm) | 10.54(Max) |
| Package width (mm) | 4.7(Max) |
| Package height (mm) | 8.46(Max) |
| Package diameter (mm) | N/R |
| Mounting surface height (mm) | 21.03(Max) |
| Install | Through Hole |
| Packaging materials | Plastic |
| package instruction | Transistor Outline Package |
| Package series name | TO |
| Package outline | Link to datasheet |
| MSL | N/R |
| Maximum reflow temperature (°C) | N/R |
| Reflow soldering time (seconds) | N/R |
| Number of reflow cycles | N/R |
| standard | N/R |
| Reflow temperature source | Link to datasheet |
| Maximum wave soldering temperature (°C) | 260 |
| Wave soldering time (seconds) | 5 |
| Wave soldering temperature source | Link to datasheet |
| Lead Finish(Plating) | Matte Sn annealed |
| Plating materials | not applicable |
| Terminal Base Material | Cu Alloy |
