• Input Voltage Range: 2.7 V to 18 V
|
• 26-V Open LED Protection for TPS61160A 38-V Open LED Protection for TPS61161A
|
• 200mV Reference Voltage With ±2% Accuracy
|
| • PWM Interface for Brightness Control
|
| • Built-in Soft Start |
| • Up to 90% Efficiency |
| • 2-mm × 2-mm × 0.8-mm 6-Pin WSON Package With Thermal Pad |
|
| CATALOG |
| TPS61160ADRVT COUNTRY OF ORIGIN |
TPS61160ADRVT PARAMETRIC INFO
|
TPS61160ADRVT PACKAGE INFO
|
TPS61160ADRVT MANUFACTURING INFO
|
TPS61160ADRVT PACKAGING INFO
|
TPS61160ADRVT EACD MODELS
|
| TPS61160ADRVT APPLICATIONS |
|
| COUNTRY OF ORIGIN |
| China |
| Malaysia |
| Philippines |
| Thailand |
|
PARAMETRIC INFO
|
| Number of Segments |
10 |
| Minimum Operating Supply Voltage (V) |
2.7 |
| Typical Operating Supply Voltage (V) |
3.3|5|9|12|15 |
| Maximum Operating Supply Voltage (V) |
18 |
| Maximum Power Dissipation (mW) |
1540 |
| Low Level Output Current (uA) |
100(Typ) |
| High Level Output Current (uA) |
100(Typ) |
| Output Voltage (V) |
2.7 to 38 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Operating Supply Voltage (V) |
2.7 to 18 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
|
|
PACKAGE INFO
|
| Supplier packaging |
WSON EP |
| Basic package type |
Non-Lead-Frame SMT |
| Number of pins |
6 |
| Pin shape |
No Lead |
| PCB |
6 |
| ears |
N/R |
| Pin spacing (mm) |
0.65 |
| Package length (mm) |
2.1(Max) |
| Package width (mm) |
2.1(Max) |
| Package height (mm) |
0.75(Max) |
| Package diameter (mm) |
N/R |
| Package Overall Length (mm) |
2.1(Max) |
| Package Overall Width (mm) |
2.1(Max) |
| Package Overall Height (mm) |
0.8(Max) |
| Mounting surface height (mm) |
0.8(Max) |
| Install |
Surface Mount |
| Package weight (g) |
not applicable |
| Packaging materials |
Plastic |
| package instruction |
Very Very Thin Small Outline No Lead Package, Exposed Pad |
| Package series name |
SON |
| JEDEC |
not applicable |
|
|
MANUFACTURING INFO
|
| MSL |
2 |
| Maximum reflow temperature (°C) |
260 |
| Reflow soldering time (seconds) |
30 |
| Number of reflow cycles |
3 |
| standard |
J-STD-020D |
| Reflow temperature source |
Link to datasheet |
| Maximum wave soldering temperature (°C) |
N/R |
| Wave soldering time (seconds) |
N/R |
| Lead Finish(Plating) |
Au |
| Plating materials |
Pd over Ni |
| Terminal Base Material |
Cu Alloy |
|
|
PACKAGING INFO
|
| Packaging Suffix |
T |
| Package |
Tape and reel packaging |
| Packing quantity |
250 |
| packaging type file |
Link to datasheet |
|
|
ECAD MODELS
|
|
|
| APPLICATIONS |
| • Cellular Phones |
| • Portable Media Players |
| • Ultra Mobile Devices |
| • GPS Receivers |
| • White LED Backlighting for Media Form Factor Display |
| |
