| Manufacturer Type |
General Purpose Amplifier |
| type |
General Purpose Amplifier |
| Rail to Rail |
Rail to Rail Input/Output |
| Minimum Single Supply Voltage (V) |
2.7 |
| Number of Channels per Chip |
2 |
| Process Technology |
BiCMOS |
| Typical Single Supply Voltage (V) |
3|5|9 |
| Maximum Single Supply Voltage (V) |
12 |
| Maximum Quiescent Current (mA) |
3@5V |
| Typical Gain Bandwidth Product (MHz) |
4 |
| Maximum Input Offset Voltage (mV) |
0.9@5V |
| Maximum Input Offset Current (uA) |
0.03@5V |
| Maximum Operating Supply Voltage (V) |
12 |
| Maximum Input Bias Current (uA) |
0.1@5V |
| Minimum CMRR (dB) |
60 |
| Maximum Supply Voltage Range (V) |
12 to 12.5 |
| Minimum CMRR Range (dB) |
60 to 65 |
| Typical Voltage Gain (dB) |
106.02 |
| Typical Slew Rate (V/us) |
1.3@5V |
| Typical Output Current (mA) |
80 |
| Typical Input Noise Voltage Density (nV/rtHz) |
9@5V |
| Shut Down Support |
no |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Power Supply Type |
Single |
