| Manufacturer Type |
General Purpose Amplifier |
| Type |
General Purpose Amplifier |
| Rail to Rail |
Rail to Rail Input/Output |
| Minimum Single Supply Voltage (V) |
4 |
| Number of Channels per Chip |
2 |
| Process Technology |
CMOS |
| Typical Single Supply Voltage (V) |
5|9|12|15 |
| Maximum Single Supply Voltage (V) |
16 |
| Output Type |
CMOS |
| Maximum Quiescent Current (mA) |
6.8@16V |
| Typical Gain Bandwidth Product (MHz) |
10 |
| Maximum Input Offset Voltage (mV) |
5@16V |
| Maximum Input Offset Current (uA) |
0.0001@16V |
| Maximum Operating Supply Voltage (V) |
16 |
| Maximum Input Bias Current (uA) |
0.0001@16V |
| Minimum CMRR (dB) |
67 |
| Maximum Supply Voltage Range (V) |
16 to 17 |
| Minimum CMRR Range (dB) |
65 to 70 |
| Typical Voltage Gain (dB) |
113 |
| Typical Slew Rate (V/us) |
16.2@16V |
| Typical Settling Time (ns) |
245 |
| Typical Output Current (mA) |
74@16V |
| Typical Input Noise Voltage Density (nV/rtHz) |
16.5@16V |
| Typical Input Bias Current (uA) |
0.00001@16V |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Supplier Temperature Grade |
Extended |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
| Power Supply Type |
Single |
