| Style |
Enclosed |
| Type |
Regulated |
| Number of Outputs |
1 |
| Output Voltage (V) |
28 |
| Input/Output Type |
AC/DC |
| Maximum Output Power (W) |
1204 |
| Maximum Output Current (A) |
43 |
| Minimum Operating Temperature (°C) |
-40 |
| Fan |
No |
| Heat Sink |
Yes |
| I2C Interface |
No |
| O-Ring Protection |
No |
| Warranty |
5Year |
| Maximum Operating Temperature (°C) |
100 |
| Line Regulation |
56mV |
| Minimum AC Input Voltage (V) |
85 |
| Maximum AC Input Voltage (V) |
305 |
| Output Connector Type |
Pin Terminal Block |
| Input Connector Type |
Pin Terminal Block |
| Power Indicator |
No |
| Output Type |
Fixed |
| Load Regulation |
56mV |
| Efficiency (%) |
91(Typ) |
| Maximum Input Current (A) |
6.7(Typ) |
| Input Frequency (Hz) |
47 to 63 |
| Minimum Isolation Voltage |
3000VAC |
| Ripple & Noise |
300mV(Max) |
| Minimum Storage Temperature (°C) |
-40 |
| Maximum Storage Temperature (°C) |
100 |
| Medical Application |
Yes |
