| Manufacturer Type |
General Purpose Amplifier |
| Type |
General Purpose Amplifier |
| Number of Channels per Chip |
1 |
| Maximum Quiescent Current (mA) |
2.8@±15V |
| Minimum Dual Supply Voltage (V) |
±3.5 |
| Typical Gain Bandwidth Product (MHz) |
1 |
| Maximum Input Offset Voltage (mV) |
6@±15V |
| Typical Dual Supply Voltage (V) |
±5|±9|±12|±15 |
| Maximum Input Offset Current (uA) |
0.2@±15V |
| Maximum Dual Supply Voltage (V) |
±18 |
| Maximum Operating Supply Voltage (V) |
±18 |
| Maximum Input Bias Current (uA) |
0.5@±15V |
| Minimum CMRR (dB) |
70 |
| Maximum Supply Voltage Range (V) |
36 to 37 |
| Minimum CMRR Range (dB) |
70 to 71 |
| Typical Voltage Gain (dB) |
106.02 |
| Typical Slew Rate (V/us) |
0.5@±15V |
| Shut Down Support |
No |
| Minimum Operating Temperature (°C) |
0 |
| Maximum Operating Temperature (°C) |
70 |
| Power Supply Type |
Dual |
| Maximum Power Dissipation (mW) |
500 |
