| Pole Throw Configuration |
SPDT |
| Switch Configuration |
N.O./N.C. |
| Maximum Current Rating (A) |
16@250VAC |
| Maximum AC Voltage Rating (V) |
250 |
| Maximum DC Voltage Rating (V) |
250 |
| Maximum Power Rating (VA) |
372.85@(CSA/UL) |
| Electrical Life (Cycles) |
100000 |
| Mechanical Life (Cycles) |
50000000 |
| Actuator Style |
Hinge Lever |
| Operating Force (N) |
1.23 |
| Release Force (N) |
0.14 |
| Contact Material |
Silver Alloy |
| Actuator Material |
Stainless Steel/N/A |
| IP Rating |
IP40 |
| Dielectric Strength |
1000VAC |
| Minimum Insulation Resistance (MOhm) |
100 |
| Maximum Movement Differential (mm) |
1.5 |
| Minimum Over-Travel (mm) |
1.6 |
| Maximum Pre-Travel (mm) |
4 |
| Maximum Operating Temperature (°C) |
105 |
| Minimum Operating Temperature (°C) |
-25 |
| Body Length (mm) |
29.4 |
| Body Depth (mm) |
10.3 |
| Body Height (mm) |
15.9 |
| Operating Temperature (°C) |
-25 to 105 |
