| CATALOG |
W2S-P012 COUNTRY OF ORIGIN
|
W2S-P012 PARAMETRIC INFO
|
W2S-P012 PACKAGE INFO
|
W2S-P012 MANUFACTURING INFO
|
W2S-P012 ECAD MODELS
|
|
COUNTRY OF ORIGIN
|
China
|
Switzerland
|
Korea (Republic of)
|
United States of America
|
Germany
|
India
|
|
PARAMETRIC INFO
|
| Type |
Wedge Lock |
| Connector Type |
Connector Rectangular |
| Material |
Plastic |
| Color |
Green |
| Operating Temperature (°C) |
-55 to 125 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
125 |
| Maximum Voltage Rating |
250VDC|250VAC |
|
|
PACKAGE INFO
|
| Body Orientation |
Straight |
| Product Length (mm) |
15.01 |
| Product Depth (mm) |
19.3 |
| Product Height (mm) |
11.58 |
| Product Diameter (mm) |
N/R |
|
|
MANUFACTURING INFO
|
| MSL |
N/R |
| Maximum Reflow Temperature (°C) |
N/R |
| Reflow Solder Time (Sec) |
N/R |
| Number of Reflow Cycle |
N/R |
| Standard |
N/R |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Lead Finish(Plating) |
N/R |
| Under Plating Material |
N/R |
| Terminal Base Material |
N/R |
| Number of Wave Cycles |
N/R |
|
|
ECAD MODELS
|
|
|
