XAZU5EV-1SFVC784Q COUNTRY OF ORIGIN
|
XAZU5EV-1SFVC784Q PARAMETRIC INFO
|
XAZU5EV-1SFVC784Q PACKAGE INFO
|
XAZU5EV-1SFVC784Q MANUFACTURING INFO
|
XAZU5EV-1SFVC784Q PACKAGING INFO
|
|
COUNTRY OF ORIGIN
|
Taiwan (Province of China)
|
|
PARAMETRIC INFO
|
| Device Logic Cells |
256200 |
| Device Logic Units |
256200 |
| Maximum Number of User I/Os |
156 |
| Number of I/O Banks |
3 |
| Device Number of DLLs/PLLs |
2 |
| Number of Multipliers |
1248 (27x18) |
| Tradename |
Zynq® |
| Number of Registers |
234240 |
| RAM Bits (Kbit) |
3584 |
| Total Number of Block RAM |
144 |
| Program Memory Type |
Flash |
| Family Name |
Zynq® UltraScale |
| Speed Grade |
1 |
| Transceiver Blocks |
4 |
| Transceiver Speed (Gbps) |
12.5 |
| Dedicated DSP |
1248 |
| Ethernet MACs |
4 |
| Copy Protection |
Yes |
| Programmability |
Yes |
| In-System Programmability |
No |
| Reprogrammability Support |
No |
| I/O Voltage (V) |
1.2|1.5|1.8|2.5|3.3 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Temperature Flag |
Opr |
| Supplier Temperature Grade |
Automotive |
| Digital Control Impedance |
Yes |
| Typical Operating Supply Voltage (V) |
0.85 |
|
|
PACKAGE INFO
|
| Supplier Package |
FCBGA |
| Basic Package Type |
Ball Grid Array |
| Pin Count |
784 |
| Lead Shape |
Ball |
| PCB |
784 |
| Tab |
N/R |
| Pin Pitch (mm) |
0.8 |
| Package Length (mm) |
23 |
| Package Width (mm) |
23 |
| Package Height (mm) |
2.72 |
| Package Diameter (mm) |
N/R |
| Seated Plane Height (mm) |
3.12 |
| Mounting |
Surface Mount |
| Package Material |
Plastic |
| Package Description |
Flip Chip Ball Grid Array |
| Package Family Name |
BGA |
| Package Outline |
Link to Datasheet |
|
|
MANUFACTURING INFO
|
| MSL |
3 |
| Maximum Reflow Temperature (°C) |
250 |
| Reflow Solder Time (Sec) |
30 |
| Number of Reflow Cycle |
3 |
| Reflow Temp. Source |
Link to Datasheet |
| Maximum Wave Temperature (°C) |
N/R |
| Wave Solder Time (Sec) |
N/R |
| Lead Finish(Plating) |
SnAgCu |
| Under Plating Material |
N/R |
| Terminal Base Material |
N/R |
|
|
PACKAGING INFO
|
| Packaging Document |
Link to Datasheet |
|
|
