| Device Logic Gates |
50000 |
| Device System Gates |
50000 |
| Device Logic Cells |
1728 |
| Device Logic Units |
1728 |
| Maximum Number of User I/Os |
92 |
| Number of I/O Banks |
8 |
| Device Number of DLLs/PLLs |
4 |
| Tradename |
Spartan |
| Maximum I/O Performance |
622Mbps |
| RAM Bits (Kbit) |
24 |
| Total Number of Block RAM |
32 |
| Program Memory Type |
SRAM |
| Maximum Distributed RAM Bits |
24576 |
| Family Name |
Spartan®-II |
| Process Technology |
150nm |
| Speed Grade |
5 |
| Shift Registers |
Utilize LUT |
| Programmability |
Yes |
| In-System Programmability |
No |
| Reprogrammability Support |
Yes |
| Maximum Internal Frequency (MHz) |
263 |
| Number of Global Clocks |
4 |
| Maximum Operating Supply Voltage (V) |
2.625 |
| I/O Voltage (V) |
1.2|1.5|1.8|2.5|3.3 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
100 |
| Temperature Flag |
Jun |
| Supplier Temperature Grade |
Industrial |
| Digital Control Impedance |
No |
| Minimum Operating Supply Voltage (V) |
2.375 |
| Typical Operating Supply Voltage (V) |
2.5 |
| Tolerant Configuration Interface Voltage (V) |
5 |
