| Device Logic Gates |
100000 |
| Device System Gates |
100000 |
| Device Logic Cells |
2160 |
| Device Logic Units |
2160 |
| Maximum Number of User I/Os |
108 |
| Number of I/O Banks |
4 |
| Device Number of DLLs/PLLs |
2 |
| Number of Multipliers |
4 (18x18) |
| Maximum LVDS Data Rate (Mbps) |
622 |
| Tradename |
Spartan |
| Number of Registers |
1920 |
| Maximum Differential I/O Pairs |
40 |
| Maximum I/O Performance |
622Mbps |
| RAM Bits (Kbit) |
72 |
| Total Number of Block RAM |
4 |
| Program Memory Type |
SRAM |
| Maximum Distributed RAM Bits |
15360 |
| Family Name |
Spartan®-3E |
| Process Technology |
90nm |
| Speed Grade |
4 |
| Transceiver Speed (Gbps) |
0.622 |
| Differential I/O Standards Supported |
LVDS|LVPECL|RSDS |
| Single-Ended I/O Standards Supported |
LVTTL|LVCMOS|SSTL|HSTL |
| JTAG Support (-) |
Yes |
| Maximum Supply Current (mA) |
36 |
| Copy Protection |
No |
| Shift Registers |
Utilize Memory |
| Programmability |
Yes |
| In-System Programmability |
Yes |
| Number of Look-up Table Input |
4 |
| Reprogrammability Support |
Yes |
| Maximum Internal Frequency (MHz) |
572 |
| Number of Global Clocks |
8 |
| Maximum Operating Supply Voltage (V) |
1.26 |
| I/O Voltage (V) |
1.2|1.5|1.8|2.5|3.3 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
100 |
| Temperature Flag |
Jun |
| Supplier Temperature Grade |
Industrial |
| Digital Control Impedance |
No |
| Minimum Operating Supply Voltage (V) |
1.14 |
| Typical Operating Supply Voltage (V) |
1.2 |
| Tolerant Configuration Interface Voltage (V) |
3.3 |
