| Device Logic Units |
24051 |
| Device Logic Cells |
24051 |
| Maximum Number of User I/Os |
266 |
| Number of I/O Banks |
4 |
| Device Number of DLLs/PLLs |
2 |
| Number of Multipliers |
38 (18x18) |
| Maximum DSP Block Frequency (MHz) |
390 |
| Tradename |
Spartan |
| Number of Registers |
30064 |
| Maximum I/O Performance |
3.2Gbps |
| RAM Bits (Kbit) |
936 |
| Total Number of Block RAM |
52 |
| Program Memory Type |
SRAM |
| Maximum Distributed RAM Bits |
234496 |
| Family Name |
Spartan®-6 LX |
| Process Technology |
45nm |
| Speed Grade |
2 |
| Transceiver Speed (Gbps) |
3.2 |
| Dedicated DSP |
38 |
| JTAG Support (-) |
Yes |
| External Memory Interface |
DDR SDRAM|DDR2 SDRAM|DDR3 SDRAM|LPDDR SDRAM |
| Copy Protection |
Yes |
| Shift Registers |
Utilize LUT |
| Programmability |
Yes |
| In-System Programmability |
No |
| Number of Look-up Table Input |
6 |
| Reprogrammability Support |
Yes |
| Number of Global Clocks |
16 |
| Maximum Operating Supply Voltage (V) |
1.26 |
| I/O Voltage (V) |
1.8|2.5 |
| Minimum Operating Temperature (°C) |
0 |
| Maximum Operating Temperature (°C) |
85 |
| Temperature Flag |
Jun |
| Supplier Temperature Grade |
Commercial |
| Digital Control Impedance |
No |
| Minimum Operating Supply Voltage (V) |
1.14 |
| Typical Operating Supply Voltage (V) |
1.2 |
| Maximum Storage Temperature (°C) |
150 |
| Minimum Storage Temperature (°C) |
-65 |
