| Device System Gates |
3000 |
| Number of User I/Os |
84 |
| Number of Logic Blocks/Elements |
8 |
| Number of Macro Cells |
128 |
| Number of Product Terms per Macro |
48 |
| Number of Inter Dielectric Layers |
5 |
| Number of Flip Flops |
128 |
| Tradename |
CoolRunner |
| Copy Protection |
No |
| Number of Global Clocks |
4 |
| Program Memory Type |
EEPROM |
| Family Name |
CoolRunner XPLA3 |
| Process Technology |
0.35um |
| Speed Grade |
10 |
| Data Gate |
No |
| Individual Output Enable Control |
No |
| Programmability |
Yes |
| In-System Programmability |
Yes |
| Reprogrammability Support |
Yes |
| Maximum Internal Frequency (MHz) |
125 |
| Maximum Operating Frequency (MHz) |
95 |
| Maximum Clock to Output Delay (ns) |
6.5 |
| Maximum Propagation Delay Time (ns) |
10 |
| Tolerant Configuration Interface Voltage (V) |
5 |
| Minimum Operating Supply Voltage (V) |
2.7 |
| Typical Operating Supply Voltage (V) |
3.3 |
| Programmable Type |
In System Programmable |
| Maximum Operating Supply Voltage (V) |
3.6 |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
85 |
| Temperature Flag |
Opr |
| Supplier Temperature Grade |
Industrial |
| Minimum Storage Temperature (°C) |
-65 |
| Maximum Storage Temperature (°C) |
150 |
